Barbed wire is a kind of modern security fencing materials,Barbed wire can be installed as deterrent to the perimeter intruders with piecing and cutting razor blades mounted at the top of the wall. Galvanized barbed wire offers a great protection against corrosion and oxidation caused by the atmosphere. Its high resistance allows greater spacing between the fencing posts. It used for grass boundary, railway, highway isolation protection
The barbed wire is twisted from a fully automated barbed wire machine. Finished product type: single wire twist and double wire twist.
Wire Materials: high quality steel wire (Electro galvanized,Hot dip galvanized,PVC coated),and PVC wire in blue,green,yellow and other colors.The core wire of PVC wire can be galvanized wire or black wire.
Characteristics: anti-corrosion,anti-ageing,solarization resistance,durable,etc.
Applications: Barbed wire is mainly used in protecting of grass boundary, railway, highway, nation defence,airport,orchard,etc. It has a excellent protective performance,beautiful appearance,various patterns.
|Galvanized barbed wire|
|Wire Diameter(BWG)||Length(meters) per Kg|
|Barb distance3”||Barb distance4”||Barb distance5”||Barb space6”|
|12 x 12||6.06||6.75||7.27||7.63|
|12 x 14||7.33||7.90||8.30||8.57|
|12.5 x 12.5||6.92||7.71||8.30||8.72|
|12.5 x 14||8.10||8.81||9.22||9.562|
|13 x 13||7.98||8.89||9.57||10.05|
|13 x 14||8.84||9.68||10.29||10.71|
|13.5 x 14||9.60||10.61||11.47||11.85|
|14 x 14||10.45||11.65||12.54||13.17|
|14.5 x 14.5||11.98||13.36||14.37||15.10|
|15 x 15||13.89||15.49||16.66||17.50|
|15.5 x 15.5||15.34||17.11||18.40||19.33|
|PVC Coated barbed wire|
|Wire Diameter||Barbs’ distance||Barb length|
|Before coating||After coating||75mm - 150mm||15mm - 30mm|
|1.0mm - 3.5mm||1.4mm - 4.0mm|
|BWG20 - BWG11||BWG17 - BWG8|
|PVC coating thickness: 0.4mm-0.6mm; different colors or length are available at customers request|
1. Materials: Q195 and Q235 or high tensile steel wire
2. Surface treatment: Hot dipped Galvanized, Electro galvanized and PVC coated
3. Tensile of Strength:
4. IOWA type, 2 strands, 4 points. Barb distance 3" to 6"
5. Applications: Widely used in Agriculture,Animal husbandry, Dwelling house,Plantation,Fencing etc.
